HZTH7510
Hua Drill
序号 | 性能项目名称 | 性能或参数 | 备 注 | |||
外形尺寸 | 长（mm） | 6060 | 拆除货叉 | |||
宽（mm） | 2380 | |||||
高（mm） | 2465 | |||||
自重（kg） | 14500 | |||||
液压系统压力（Mpa） | 26 | |||||
液压系统流量(l/min) | 145 | |||||
发动机 | 型号 | QSB4.5(97kw，130HP) | 国三 | |||
功率(kw@rev) | 97/2200 | |||||
扭矩（N@rev） | 600N.M/1500 | |||||
最大行走速度（km/h） | 25 | |||||
爬坡度（°） | 30% | |||||
离去角（°） | 28 | |||||
后桥车架摆动角度（°） | 8 | |||||
轮胎规格Tire specification | 18-24 | |||||
液压油箱Hydraulic oil tank | 160 L | |||||
柴油油箱Diesel oil tank | 150 L | |||||
液压泵Hydraulic pump type | Gear Pump for power steering and movements | |||||
臂举升速度Boom lifting Speed | 15.1 s | |||||
臂前伸速度Boom Extension Speed | 10.4 s | |||||
Hua Drill telescopic handlers enjoy proven demand supported by legendary productivity and build quality, ensuring high residuals the world over. DieselMAX can be adapted to run on lower-grade fuels, making Construction telehandlers easily resalable across different states and territories, boosting residuals further still.
Multi-function single lever servo control provides fast and accurate load placement. Controlling your Hua Drill telehandler’s direction is easy too, with just a flick of a switch.
Powerful performance and versatility with excellent manoeuvrability
State of the art design and manufacturing to ensure strength, durability and reliability are built in
Easy to use cab controls, excellent visibility and the ultimate in operator comfort
Extremely low operator costs, and high residual value
The ultimate in operator and machine safety
Your telehandler operators can manoeuvre quickly and easily with directional shuttle changes possible via either the shuttle lever on the steering column or the joystick-mounted shuttle switch.
These telescopic handlers have three selectable 4-wheel steering modes. Two-wheel steer is perfect for roading; four-wheel steer provides great manoeuvrability in tight spaces; and crab steer can help to edge either close to or away from obstacles
