HZTH4507
Hua drill
The dedicated chassis can achieve front wheel steering (default mode), four-wheel steering, and crab driving. Closed static pressure drive is adopted during driving, mainly composed of driving wheels, non independent steering system, frame, and electronic control system; the power source of the hydraulic system is the engine, and load sensitive hydraulic systems such as the main boom luffing cylinder, telescopic cylinder, and active leveling cylinder of the boom head are used for on-car operation.
front wheel steering, four wheel steering , crab wheel steering.
what is telehandler uses for ?
In industry, the most common attachment for a telehandler is pallet forks and the most common application is to move loads to and from places unreachable for a conventional forklift. For example, telehandlers have the ability to remove palletised cargo from within a trailer and to place loads on rooftops and other high places. The latter application would otherwise require a crane, which is not always practical or time-efficient.
序号 | 性能项目名称 | 性能或参数 | 备 注 | |||
1. | 外形尺寸 | 长（mm） | 5150 | 拆除货叉 | ||
宽（mm） | 2250 | |||||
高（mm） | 2300 | |||||
2. | 自重（kg） | 7900 | ||||
3. | 液压系统压力（Mpa） | 26 | ||||
4. | 液压系统流量(l/min) | 145 | ||||
5. | 液压油箱容积(l) | 150 | ||||
6. | 发动机 | 型号 | QSB3.9-C110-30 | 国三 | ||
7. | 功率(kw@rev) | 81/2200 | ||||
8. | 扭矩（N@rev） | 480/1600 | ||||
9. | 最大行走速度（km/h） | 25 | ||||
10. | 爬坡度（°） | 30% | ||||
11. | 离去角（°） | 33 | ||||
12. | 后桥车架摆动角度（°） | 5 | ||||
13. | 轮胎规格 | 16.70-20 or 16.70-24 | ||||
