Hua Drill telescopic handlers enjoy proven demand supported by legendary productivity and build quality, ensuring high residuals the world over. DieselMAX can be adapted to run on lower-grade fuels, making Construction telehandlers easily resalable across different states and territories, boosting residuals further still.
| Quantity: | |
|---|---|
HZTH3507
Hua Drill
Class-leading Hua drill hydraulics produce the fastest cycle times, ensuring the most efficient lifting, extending and pushing.
Multi-function single lever servo control provides fast and accurate load placement. Controlling your Hua Drill telehandler’s direction is easy too, with just a flick of a switch.
S/N | Name of performance project | Remark | |||
HZTH3507 | |||||
1. | SIZE | （mm）L | 5000 | Removed fork | |
（mm）W | 2220 | ||||
（mm）H | 2410 | ||||
2. | （kg）Weight | 7350 | |||
3. | （Mpa） Hydraulic system pressure | 30 | |||
4. | (L/min) Hydraulic system flow | 145 | |||
5. | (L) Tank | 120 | |||
6. | engine | Mold | QSB3.9-C100-30 | ||
7. | Power (kw@rev) | 74/2200 | |||
8. | Torque （N@rev） | 480/1600 | |||
9. | （km/h）Max. Speed | 25 | |||
10. | Gradeability（°） | 40% | |||
11. | Departure angle（°） | 33 | |||
12. | Swing angle of rear axle frame（°） | 5 | |||
13. | Tire | 14-16.5 12pr | |||
Class-leading Hua drill hydraulics produce the fastest cycle times, ensuring the most efficient lifting, extending and pushing.
Multi-function single lever servo control provides fast and accurate load placement. Controlling your Hua Drill telehandler’s direction is easy too, with just a flick of a switch.
S/N | Name of performance project | Remark | |||
HZTH3507 | |||||
1. | SIZE | （mm）L | 5000 | Removed fork | |
（mm）W | 2220 | ||||
（mm）H | 2410 | ||||
2. | （kg）Weight | 7350 | |||
3. | （Mpa） Hydraulic system pressure | 30 | |||
4. | (L/min) Hydraulic system flow | 145 | |||
5. | (L) Tank | 120 | |||
6. | engine | Mold | QSB3.9-C100-30 | ||
7. | Power (kw@rev) | 74/2200 | |||
8. | Torque （N@rev） | 480/1600 | |||
9. | （km/h）Max. Speed | 25 | |||
10. | Gradeability（°） | 40% | |||
11. | Departure angle（°） | 33 | |||
12. | Swing angle of rear axle frame（°） | 5 | |||
13. | Tire | 14-16.5 12pr | |||
